Gear repair servo front seat thigh support
BMW OEM 52107120189, 52107068045, 52100309476
On the problem:
As is known, the servo front seat thigh support BMW factory installed plastic gear, which over time break down the teeth.
Pressing the servo motor of thigh support sound is heard, but the thigh support does not extend.
The reason is that broken teeth on the plastic gear.
The cost of the new electric drive is about $ 250.
We produce and sell a new worm-gear made of brass.
For repair of motor thigh support is sufficient to replace the broken gear to the new.
5′ E60 (12/2001 — 12/2009)
5′ E60 LCI (10/2005 — 12/2009)
5′ E61 (10/2002 — 02/2007)
5′ E61 LCI (11/2005 — 05/2010)
5′ F07 GT (09/2008 — 06/2013)
5′ F10 (01/2009 — 03/2015)
5′ F11 (01/2009 — 06/2013)
7′ E65 (02/2000 — 07/2008)
7′ E66 (06/2000 — 07/2008)
7′ E67 (10/2002 — 06/2008)
7′ F01 (06/2007 — 06/2012)
7′ F02 (07/2007 — 06/2012)
7′ F03 (04/2008 — 05/2012)
7′ F04 Hyb (10/2008 — 06/2012)
X5 E70 (02/2006 — 06/2013)
X5 E70 LCI (04/2009 — 06/2013)
X6 E71 (01/2007 — 06/2014)
X6 E72 Hyb (10/2008 — 10/2011)
Rolls Royce Phantom
Gear servo-thigh support BMW
Often the driver’s and the passenger seats of cars equipped with popliteal support (on a relatively fresh car, this support features an automatic movement). As a result, when you click on the popliteal support is driven by a servo. After the time that the device ceases to perform its function. To troubleshoot you need to start the mechanism. If you hear the sound of the motor (electric motor catalog 52107068045 or 52107120189), but the popliteal support BMW does not move or is acting up (sticking) when driving, it indicates a failure of the gear seat, and the means required to repair seat bmw.
With plant inside the servo is plastic gear, but the plastic is not very durable material and therefore in the process of operation, he ages quickly, becomes brittle and fails, in this regard, plastic gear motor seat and will periodically break down.
To repair support car owners BMW offered to buy the entire part Assembly “servo-thigh support” (the code parts 52100309476), which costs $250. And many motorists repair seats BMW that way. But we figured out how to get rid of this “headache” once and for all, and spend a while in less than 6 times.
Our company produces and sells gear servo-thigh support BMW for replacement of high-strength and durable material – brass. Replacing a gear once, you’ll never have to repair seats bmw connected drive.
Manual sample repair seats BMW E60:
1. Remove the bolts and disconnect the seat heater.
2. Very carefully remove the plastic overlay, which is fixed by two clips.
3. To turn off the motor and remove the spare.
4. Remove the screws (3 white and 3 black) and remove the 5 plastic clips.
5. Assemble the mechanism together (pull-out part should be on the same level)
6. Open a plastic panel.
7. Retrieved the broken plastic gear and put in its place a new gear from brass.
Assembly in reverse order.
Repair seat BMW finished.
Now the operation of the servo-thigh support is restored and he no longer needs to be replaced.
